INSTALLATION INSTRUCTIONSWALL MOUNTEDPACKAGE AIR CONDITIONERSMODELSWA421WA482WA602Manual : 2100-218ISupersedes: 2100-218HFile: Volume III Tab 16Date

Manual 2100-218Page 8FIGURE 3MOUNTING INSTRUCTIONSMIS-416

Manual 2100-218Page 9 WARNINGA minimum of 1/4 inch clearance must be maintained between thesupply air duct and combustible materials. Th

Manual 2100-218Page 10FIGURE 5WALL MOUNTING INSTRUCTIONSFIGURE 6WALL MOUNTING INSTRUCTIONSMIS-548MIS-549SEE FIGURE 3 – MOUNTING INSTRUCTIONSSUPP

Manual 2100-218Page 11FIGURE 7COMMON WALL MOUNTING INSTALLATIONSFREE AIR FLOW NO DUCTDUCTED SUPPLY RETURN AT UNITFALSE WALL INSTALLATIONCLOSET

Manual 2100-218Page 12WIRING – MAIN POWERRefer to the unit rating plate for wire sizing informationand maximum fuse or “HACR” type circuit breake

Manual 2100-218Page 13FIGURE 8UNIT 24V TERMINAL BOARDMIS-1373

Manual 2100-218Page 14THREE PHASE SCROLL COMPRESSORSTART UP INFORMATIONScroll compressors, like several other types ofcompressors, will only compre

Manual 2100-218Page 15Low Pressure Switch, Bypass, and LockoutSequenceIf the low pressure switch opens for more than 120seconds, the compressor c

Manual 2100-218Page 16PRESSURE SERVICE PORTSHigh and low pressure service ports are installed on allunits so that the system operating pressures ca

Manual 2100-218Page 17REMOVAL OF FAN SHROUD1. Disconnect all power to the unit.2. Remove the screws holding both grilles, one on eachside of unit

ContentsFiguresFigure 1 Unit Dimensions ... 3Figure 2 Fresh Air Damper Assembly ... 6Figure 3 Mount

Manual 2100-218Page 18ledoMdetaR*MFCdetaR*PSEdednemmoceRegnaRwolfriA124AW004103.0511-0061284AW055102.5821-0571206AW007103.5731-0591TABLE 8RECOMMEN

Manual 2100-218Page 19traPrebmuNnoitpircseD50A-50AWHE80A-50AWHE01A-50AWHE51A-50AWHEsegakcaPretaeHsegakcaPretaeHsegakcaPretaeHsegakcaPretaeHXXXXXX

Manual 2100-218Page 1Getting Other Information and PublicationsThese publications can help you install the air conditioneror heat pump. You can u

Manual 2100-218Page 2WALL MOUNT GENERAL INFORMATIONHEAT PUMP WALL MOUNT MODEL NOMENCLATUREWA 42 1 – A 10 X N X X X

Manual 2100-218Page 3FIGURE 1UNIT DIMENSIONSMIS-1262ledoMhtdiW)W(htpeD)D(thgieH)H(ylppuSnruteREFGIJKLMNOPQRSTABCB24AW84AW570.24234.22578.4888.98

Manual 2100-218Page 4➀➁➂TABLE 2ELECTRICAL SPECIFICATIONSMaximum size of the time delay fuse or HACR type circuit breaker for protection of field w

Manual 2100-218Page 5SHIPPING DAMAGEUpon receipt of equipment, the carton should be checkedfor external signs of shipping damage. If damage isfo

Manual 2100-218Page 6FRESH AIR INTAKEAll units are built with fresh air inlet slots punched in theservice panel.If the unit is equipped with a fres

Manual 2100-218Page 7INSTALLATION INSTRUCTIONS WARNINGFailure to provide the 1/4 inch clearancebetween the supply duct and a combustiblesu
